A small integrated processor module with highest performance for intelligent embedded solutions
|
pLILLY-M91-S-208 |
SoM with i.MX91 CPU SC 1.4GHz, DRAM 2GB, eMMC 8GB with 100 pin system bus IF connector |
|
Dimensions: |
Length = 51 / Width = 40 / Height = 6mm / Weight = 10g |
Other options on request
| CPU | SoC NXP Single Core i.MX91 Cortex™ A55 1,4GHz |
|---|---|
| Coprocessor | AI/ML NPU 0,5 TOPS |
| Memory | DRAM: LPDDR4L 2GB |
| Flash / Slot | eMMC Flash 8 up to 64GB, On Board 1x MICRO SD Card Slot |
| Periphery | Real-time clock with interface to buffer battery, WD- Timer |
| network | 1x CAN BUS FD IF, 2x 1Gb Ethernet IF |
| Interfaces | 3x USB2.0 Host IF, 3x UART IF, I²C- Bus IF, GPI/O IF, 1x 18bit RGB Display IF, SPI-BUS IF, B2B system bus 100Pin |
| power supply | Power V in: + 3,3V DC |
| Operating System | LINUX x.x., Buildroot, Jocto |
